Industrial Computing / Fanless Computer / Nuvo-7505D Series

Nuvo-7505D Series

Intel® 9th/ 8th-Gen Core™ i7/i5/i3 compact fanless embedded computer with isolated DIO, isolated COM and 2x GbE

Features and Benefits:

• Compact 255 x 173 x 76 mm footprint
• Intel® 9th/ 8th-Gen Core™ 35W LGA1151 CPU
• Rugged, -25°C to 60°C fanless operation
• 2x GbE and 4x USB 3.1 Gen1
• 6x COM ports, isolation on ports 1~ 4
• VGA + DVI dual display outputs
• Accommodates one 3.5" or 2.5" HDD/ SSD
• 8-CH isolated DI and 8-CH isolated DO

Certifications

DATASHEET DOWNLOAD  GET A QUOTE

---

Introduction

Nuvo-7505D is a cost-effective, compact and yet powerful fanless embedded computer with a 255 x 173 x 76 mm footprint. Powered by an Intel® 9th/ 8th-Gen Core™ hexa/ octa core CPU, it offers more than 50% computation performance improvement over the previous generation.

Nuvo-7505D is designed to be simple and compact while retaining essential elements of a rugged embedded fanless solution. It features I/Os such as 2x GbE, 4x USB 3.1 Gen1 and 6x COM ports for common industrial applications. In addition to the M.2 2280 SATA SSD, it can also support a 2.5" SSD/ HDD or a 3.5" HDD. Besides, Nuvo-7505D offers isolated DIO and isolated COM, which can protect the controller against ground loops in harsh environments.

The Nuvo-7505D is a cost-effective solution that has retained quality materials all Neousys systems utilize; and the design flow/ stringent test procedures it must endure. It is a fanless embedded platform that has hit the sweet spot in terms of cost, size and performance. Nuvo-7505D is an ideal fanless embedded solution for various industrial applications.

---

Product Highlights
