MD-124

24-inch marine display with wide viewable image size

MD-124

Introduction

The MD-124 Series has been designed to fit the peculiar environmental demands of maritime industrial systems. The 24-inch panel features a 16:9 aspect ratio and a 1920 x 1080 pixel resolution, making this display ideal for any marine application requiring detailed, high-resolution imagery. In addition, with full range dimming, optical bonding (Y models only), and designed with 2D, 178° wide angle viewing, these computer display terminals satisfy a variety of international maritime standards.

Explore Marine Colors with ECDIS Reliability

DATASHEET DOWNLOAD


Industrial Grade Marine Display Features

  • 24-inch wide screen with 16:9 aspect ratio and 1920 x 1080 pixel resolutionDownload ECDIS Marine Brochure
  • 300 cd/m2 backlight luminance eases eyestrain for comfortable viewing
  • PIP/PBP give viewing option so that crew may arrange information to meet any need
  • Independent DC and AC power connectors (24 VDC, 110 to 230 VAC) allow for installation flexibility
  • Rugged design with IP66 rated front panel
  • Industrial Grade Operating Temperature: -15 to 55°C (5 to 131°F)
  • Anti-Vibration design compliant with IEC 60945 DNV 2.4, Class A/Class C

Flexible options for different marine display demand

  • Optically bonded models increase panel contrast and overall visibility under bright sunlight
  • Surface capacitive touch screens give fast, sensitive response with excellent dragging performance
  • Color calibration to meet the ECDIS display standard (IEC 61174) is available for all models
